PERENCANAAN SISTEM AIR BERSIH DAN DRAINASE DI PERUMAHAN PURI BRAWIJAYA BANYUWANGI

Supply of clean water has an important role as one of the sources of the needs of living
things, especially humans. it is necessary to plan a clean water distribution system and
drainage system as a proper utilization, management, and control of clean water and
drainage. Puri Banyuwangi housing stands on 13.6 hectares of land and has 598 units
divided into 2 types of housing units. Planning for clean water distribution and drainage
systems is planned in a state where the house is 100% occupied, in accordance with
calculations and based on siteplan map data, topographic maps, and maximum rainfall
data in the area. From the analysis of the calculation of clean water demand in the
domestic sector it can be worth 4.672 liters / second, for the non-domestic sector 0.144
liters / second. There is a water loss of 0.963 liters / second The maximum clean water
requirement reaches 6.646 liters / second. Calculation of clean water so that it can be
distributed thoroughly using AW type PVC pipes measuring 0.022 m and 0.026. Analysis
and simulation using the WaterNet application, obtained a minimum relative energy of
0.5 m, and a maximum energy of 23.97. Drainage network planning with a 2-year return
period rainwater discharge of 0.1785 m3/second while domestic waste is 0.00531
m3/second. Channel dimensions used: 40 cm high, 20 cm wide base, and 40 cm high, 40
cm wide base.
