Ma ruf, Abdul (2009) PENGUKURAN REGANGAN PADA BATANG KUNINGAN DENGAN MENGGUNAKAN STRAIN GAUGE. Other thesis, University of Muhammadiyah Malang.


Download (9kB) | Preview


Struktrural rod which has flexibility due to resistance to the applied load is called the block. The blocks are not only capable of supporting the load that will receive, but also must be able to overcome the deflection to a certain extent with different weight and location specific pedestal voltage to be searched. Measurement of stress and strain is the basis of the design of the kritreria strength. A form of design criteria can be based on the strength or rigidity and stability. In the loading acting on the block cause the block be flexible so that its axis is deformed shape of the curve. By knowing the stress and strain, we can analyze and design a beam that has a variety of loading conditions. Measurements conducted Measure aims to stretch that occurs at a particular point due to loading and stress that occurs Looking at some point due to loading and comparing the results of calculations with ANSYS 8.0. From the results of the comparison voltage difference occurs a very large value, is due to not following the installation prosuder strain gauge sensors contained in the handbook.

Item Type: Thesis (Other)
Subjects: T Technology > TJ Mechanical engineering and machinery
Divisions: Faculty of Engineering > Department of Mechanical Engineering (21201)
Depositing User: Anggit Aldila
Date Deposited: 19 Jun 2012 03:59
Last Modified: 19 Jun 2012 03:59
