PENGUKURAN REGANGAN PADA BATANG KUNINGAN DENGAN MENGGUNAKAN STRAIN GAUGE

RACHMAN, SALMAN (2009) PENGUKURAN REGANGAN PADA BATANG KUNINGAN DENGAN MENGGUNAKAN STRAIN GAUGE. Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
PENGUKURAN_REGANGAN_PADA_BATANG_KUNINGAN_DENGAN_MENGGU.pdf

Download (51kB) | Preview

Abstract

Struktrural rod which has flexibility due to resistance to the applied load is called the block. The blocks are not only capable of supporting the load that will receive, but also must be able to overcome the deflection to a certain extent with different weight and location specific pedestal voltage to be searched. Measurement of stress and strain is the basis of the design of the kritreria strength. A form of design criteria can be based on the strength or rigidity and stability. In the loading acting on the block cause the block be flexible so that its axis is deformed shape of the curve. By knowing the stress and strain, we can analyze and design a beam that has a variety of loading conditions. Measurements conducted Measure aims to stretch that occurs at a particular point due to loading and stresses that occur Looking at some point due to loading and comparing the results with ANSYS calculation of voltage ratio results obtained from the calculation, it is known that the ratio by using strain gage sensors are very small

Item Type: Thesis (Other)
Subjects: T Technology > TJ Mechanical engineering and machinery
Divisions: Faculty of Engineering > Department of Mechanical Engineering
Depositing User: Anggit Aldila
Date Deposited: 26 Jun 2012 07:54
Last Modified: 26 Jun 2012 07:54
URI: http://eprints.umm.ac.id/id/eprint/9708
