MUSGIONO, MUSGIONO (2007) REDESIGN MESIN PENGHANCUR KERTAS KAPASITAS 50 KG/MENIT. Other thesis, University of Muhammadiyah Malang.


Download (70kB) | Preview


Cycling of paper Waste of paper before in making paper become is beforehand destroy to become the pulp of paper (pulp paper) bland by using machine of paper destroyer. Machine of paper Destroyer recycle to work by system like squealer process , with the knife turn around as destroyer. Early process is crushing, that is paper and water is 70 % paper and 30 % water into machine pass the funnel later then in a state of working machine will rotate to turn around the knifes turn so that happened the process of paper crushing, paper will be cut according to machine rotation until the paper fall to pieces to mixed with the water become the pulp paper, later then pulp paper go out to pass the out pipe. Planning of this paper destroyer Machine is made by using electromotor as its activator with reduced by belt attached at pulley and rotate to move the crank shaft converging the knife as knife situation turn around the. Machine of paper Destroyer recycle this planned by capacities 15 kg/ minute with the knife amount 8 ,thick of knife 3 mm, wide 40 mm and long 200 mm, as for rotation of crank shaft is 675 rpm, while countershaft rotation is 2700 rpm

Item Type: Thesis (Other)
Subjects: T Technology > TJ Mechanical engineering and machinery
Divisions: Faculty of Engineering > Department of Mechanical Engineering
Depositing User: Zainul Afandi
Date Deposited: 22 Jun 2012 04:07
Last Modified: 22 Jun 2012 04:07
