STUDI PERENCANAAN STRUKTUR ATAS PROYEK PEMBANGUNAN SEKOLAH NASIONAL BERTARAF INTERNASIONAL, SD MODEL KOTA MALANG MENGGUNAKAN BALOK GRID (SK SNI 2002)

Mahrus, Mohammad (2009) STUDI PERENCANAAN STRUKTUR ATAS PROYEK PEMBANGUNAN SEKOLAH NASIONAL BERTARAF INTERNASIONAL, SD MODEL KOTA MALANG MENGGUNAKAN BALOK GRID (SK SNI 2002). Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
STUDI_PERENCANAAN_STRUKTUR_ATAS_PROYEK_PEMBANGUNAN_SEKOLAH_NASIONAL_BERTARAF_INTERNASIONAL.pdf

Download (70kB) | Preview

Abstract

Grid block structure was formed from the general space application to the large spread. By the grid block (cross block) and the usage of thin sheet, there would be reduced the large sag. Beside as structure, grid block was also useful for beautiful decoration ceiling. Skeletal concrete structure in grid block design used 100 mm plat thickness for ceiling sheet and 120mm for floor sheet, the length of grid block 1.5m x 2m. The skeletal sheet used Ø8 – 100 (As = 502.7mm2). Grid block dimension planned to be 250/400mm for x direction and 200/350 mm for y direction. While the primary block planned 400/600 mm. Grid block skeletal in the roof found 4Ø13 to x direction and for y also get 4Ø13. The primary cross block used 5D16 skeletal for axis and field used 5D16. While in length direction, there found 5D16 skeletal for axis and 5D16 also for field with crossbar distance D10-150

Item Type: Thesis (Other)
Subjects: T Technology > TA Engineering (General). Civil engineering (General)
Divisions: Faculty of Engineering > Department of Civil Engineering
Depositing User: Anggit Aldila
Date Deposited: 19 Jun 2012 04:08
Last Modified: 19 Jun 2012 04:08
URI: http://eprints.umm.ac.id/id/eprint/8504
