POWER ANALYZER BERBASIS NATIONAL INSTRUMENTS LABVIEW 8.2 DAN NI-DAQ USB

KRISMADA, R HENDY (2009) POWER ANALYZER BERBASIS NATIONAL INSTRUMENTS LABVIEW 8.2 DAN NI-DAQ USB. Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
POWER_ANALYZER_BERBASIS_NATIONALINSTRUMENTS_LABVIEW_8.2_DAN_NI-DAQ_USB.pdf - Published Version

Download (86kB) | Preview

Abstract

Problems in the field of Electric Power System (STL) become increasingly complex today. Because the variables are measured not only the voltage, power, and current, but also the apparent, active power, reactive power, power factor, and harmonic components of the current and voltage. These quantities can be measured using the Power Analyzer available in the market. This is the basis in designing Power Analyzer. Power Analyzer is connected to the Personal Computer (PC) 8.2 as a LABVIEW-based software for programming and NI-DAQ 6008 as the hardware for data acquisition that can later be analyzing these variables. Power Analyzer is designed for measuring electrical quantities a). effective voltage b). Effective current c). Power d). Apparent Power e). Reactive power f). Power factor, and g). Total harmonic distortion of voltage and current.

Item Type: Thesis (Other)
Subjects: T Technology > TK Electrical engineering. Electronics Nuclear engineering
Divisions: Faculty of Engineering > Department of Electrical Engineering
Depositing User: Anwar Jasin
Date Deposited: 15 Jun 2012 06:40
Last Modified: 15 Jun 2012 06:40
URI: http://eprints.umm.ac.id/id/eprint/7970
