STUDI ALTERNATIF PERENCANAAN STRUKTUR ATAS JEMBATAN BUSUR RANGKA BAJA PADA JEMBATAN JELAI KABUPATEN SUKAMARA - KALTENG

PARMONO, GUSTI RIKI (2008) STUDI ALTERNATIF PERENCANAAN STRUKTUR ATAS JEMBATAN BUSUR RANGKA BAJA PADA JEMBATAN JELAI KABUPATEN SUKAMARA - KALTENG. Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
STUDI_ALTERNATIF_PERENCANAAN_STRUKTUR_ATASJEMBATAN_BUSUR_RANGKA_BAJAPADA_JEMBATAN_JELAIKABUPATEN_SUKAMARA.pdf

Download (84kB) | Preview

Abstract

Bridge of Jelai representing link among Sub-Province of Sukamara-Kalteng with Sub-Province of Ketapang-Kalbar. This Bridge get through so called river of Jelai representing frontier among both town. A bridge with length 120 m and wide 9 m. In order to realizing " landmark" sub-province of Sukamara as new sub-province, hence writer give an alternative form more signalizing bridge of esthetics form that is with form construct steel bow. Frame steel arc bridge represent one of the structure form of bridge having big strength in overcoming lendutan that is by using form of bow. All laboring burdens at vehicle floor will be distributed to entire all bow construct to pass hangers. To analyse planning of frame become militant bow and its its use method of LRFD where this method offer concept which is on its principle, using factor reduce factor and strength excess of burden so that enable creation an economic and peaceful steel construction. From result of planning analysis, dimension of used bow frame that is for the bar of curve to the using profile of WF 400.400.30.50, bar of curve under profile use of WF 400.400.45.70, vertical bar use profile of WF 400.400.15.15 and diagonal bar use profile of WF 400.200.7.11. While for to long gelagar use profile of WF 400.200.8.13 and for athwart gelagar of profile of WF 900.300.18.34.

Item Type: Thesis (Other)
Subjects: T Technology > TA Engineering (General). Civil engineering (General)
Divisions: Faculty of Engineering > Department of Civil Engineering
Depositing User: Anggit Aldila
Date Deposited: 28 May 2012 02:51
Last Modified: 28 May 2012 02:51
URI: http://eprints.umm.ac.id/id/eprint/5992
