Wicahyo Putro, Teguh Gito (2010) PERANCANGAN, PEMBUATAN, DAN PENGUJIAN ALAT UJI GETARAN PAKSA MENGGUNAKAN SISTEM AKUISISI DATA. Other thesis, University of Muhammadiyah Malang.

PERANCANGAN.pdf - Published Version

Download (52kB) | Preview


Vibration experimental tool use the data acquisition system data is vibration experimental tool that can be used as practice tool which can support in mechanic vibration subject. We have been planning vibration experimental tool that focus on conceptual planning because in this step creativities and factual ability are needed. And then from that conceptual planning we can make a vibration experimental tool. In experimental of of this tool use data acquisition system with LabVIEW Signal Express software which is now belongs to Mechanical Engineering Laboratory, Muhammadiyah University of Malang. The result of the experimental data acquisition vibration tool can be found natural frequency value about 206.51 rad/s with frequency (f) is 33.0 Hz, however with FEM ( finite Element Method ) can be found natural frequency 105.8 rad/s with frequency (f) 16.84 Hz, and theoretically can be found natural frequency value with 105.78 rad/s with frequency (f) 16.83 Hz The conclusion is we can found vibration experimental tool makes use acquisition system data with simple supported beam. With the length of beam 0,25 m, width 0.02465 m, high 0.00270 m, unbalance mass 0.005 kg. The mass of motor 0.880 Kg, radius eccentricity 0.032 m, and natural frequency value 206.51 rad/s with frequency (f) 33.0 Hz.

Item Type: Thesis (Other)
Subjects: T Technology > TJ Mechanical engineering and machinery
Divisions: Faculty of Engineering > Department of Mechanical Engineering (21201)
Depositing User: Rayi Tegar Pamungkas
Date Deposited: 19 Mar 2012 14:20
Last Modified: 19 Mar 2012 14:20
