PERANCANGAN PEMBUATAN CETAKAN VELG RACING SEPEDA MOTOR DENGAN MENGGUNAKAN CETAKAN PASIR

BHERLIARTO, R. WILDAN (2007) PERANCANGAN PEMBUATAN CETAKAN VELG RACING SEPEDA MOTOR DENGAN MENGGUNAKAN CETAKAN PASIR. Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
PERANCANGAN_PEMBUATAN_CETAKAN_VELGRACING_SEPEDA_MOTOR_DENGANMENGGUNAKAN_CETAKAN_PASIR.pdf

Download (9kB) | Preview

Abstract

Even in this time have many industrial home which make racing velg to various motor vehicle type, but just remain to be newfangled can be made other choice. To that's making designed of racing velg mould process use sand mold. Scheme of making mould for this racing velg use calculation of channel system. Scheme of process casting of this racing velg use raw material for casting is aluminium alloy of standard Alcan with materials number of B135, raw material for pattern is mahony wood, raw material of mould is dry sand with fixative cement and also construct mould of sawn timber. After known of volume value of casting equal to 1,527.47 cm3 is finally known also heavily casting equal to 4.1 kg, infusion time 12 second, volume decant 145,522.39 mm3 / sec. For channel go down height 274.3 mm, its diameter 15 mm, wide of its slice 176.6 mm2, area choke 62.76 mm2. For channel enter wide [of] its slice 353.25 mm2, length 188 mm. For cup decant its deepness 67.5 mm, length 150 mm, width 60 mm. For the channel of adder of its diameter 119.2 mm, height 238.5 mm. For the vent of its diameter 5mm, height 238.5 mm, its amount 2. Measure construct mould 930 x 740 x 384 (mm). The finishing process with cleaning process, machining process with grinding and lathe, process attenuation of surface and last is painting process.

Item Type: Thesis (Other)
Subjects: T Technology > TJ Mechanical engineering and machinery
Divisions: Faculty of Engineering > Department of Mechanical Engineering
Depositing User: Zainul Afandi
Date Deposited: 07 May 2012 06:54
Last Modified: 07 May 2012 06:54
URI: http://eprints.umm.ac.id/id/eprint/4519
