SISTEM PENGATURAN KECEPATAN PUTAR MOTOR DC MENGGUNAKAN KONTROLLER PID BERBASIS PEMROGRAMAN MATLAB DENGAN INTERFACE MF 624

HABIBI, ALI (2008) SISTEM PENGATURAN KECEPATAN PUTAR MOTOR DC MENGGUNAKAN KONTROLLER PID BERBASIS PEMROGRAMAN MATLAB DENGAN INTERFACE MF 624. Other thesis, University of Muhammadiyah Malang.

[img]
Preview
Text
SISTEM_PENGATURAN_KECEPATAN.pdf

Download (87kB) | Preview

Abstract

Commonly in control systems is recognized several kind control action, among others control action proporsional,integral ,and derivative.Each control action have certain excellence,that is proporsional control action have excellence of time rise which quickly. integral control action have excellence to minimize error. derivative control action have excellence to minimize or weaken overshot / undershot. PID controller will control every variable situation of motor of DC which measured for feedback. By applying control systems theory is got ease in obtaining performance ,at the same time improve the response of dynamic systems as expected. This research will applying and specification the discuss in arrange the DC motor .Then controller that used is PID controller that connected by realtime with hardware using I/O Board MF 624.Parameter determination of PID controller using method of root locus. By using stability of root-Locus can know position of pole and zero so that can searched the value of PID controller.By using PID controller at simulation had found the performance system that better than before, respon output of natural system stable situation in a short time that is 2 second with time delay 0.1 second.While at simulation by realtime with MF 624 system reinforcement as according to value which is wanted.

Item Type: Thesis (Other)
Subjects: T Technology > T Technology (General)
Divisions: Faculty of Engineering > Department of Electrical Engineering
Depositing User: Anggit Aldila
Date Deposited: 03 May 2012 08:24
Last Modified: 03 May 2012 08:24
URI: http://eprints.umm.ac.id/id/eprint/4182
